Spectral Imaging Series

Spectral Imaging Series

Dedicated to providing snapshot, miniaturized array spectral imaging products for innovative applications of consumer electronics, AIOT and general industry customers, this series supports flexible customization of spectral channel number and spatial resolution, with a variety of response bands, high integration and low-cost characteristics.
Different from the traditional spectral imaging products such as prism dispersion, grating diffraction, or interference spectroscopy, it does not need the combination of precise devices and the inherent optical path required by spectrophotometry, thus greatly reducing the volume and cost. Meanwhile, it solves the existing spectral imaging technology with point-by-point and line-by-line scanning or wavelength scanning mode, which cannot obtain real-time spectral information of each pixel in the field of view and other pain points, with real-time array spectral imaging solutions for applications in a wide range of fields.
SEETRUM spectral imaging technology integrates thousands of tiny spectrometers on a button-sized chip to enable rapid spectral imaging of large-scale arrays. This advanced technology development portfolio of sensor IC, integrate modular product portfolios, associated algorithms and software has great potential for portable, hand-held, or miniaturized devices with great potential for innovative applications in consumer electronics, machine vision, digital agriculture, smart health, environment and many areas.

Spectral Imaging Series

PRODUCT ADVANTAGES

Miniaturization

Miniaturization

Small micro size, easy integration

Snapshot imaging

Snapshot imaging

Real-time imaging, efficient and informative

Reconfigurable

Reconfigurable

Flexibly customized spectral channel number and spatial resolution

PRODUCT LIST

If you are interested in cooperation, please contact us:[email protected]

Customized Model

Customized Model

Provides multi-dimensional customized product development services, including but not limited to:

Spatial resolutionUp to billions of pixels

Wavelength rangeUltraviolet、visible light、near-infrared shortwave、near-infrared longwave、mid-far infrared、etc.

Spectral resolution/Spectral channelsUp to 0.5nm/Up to thousands of channels

Packaging formsChip、module、etc.

Data interfacesSPI、MIPI、etc.

SEE7810

SEE7810

Snapshot VIS-NIR Multi-spectral Imaging Module

SEE7810 dedicated to providing snapshot, miniaturized array spectral imaging products for innovative applications of consumer electronics, AIOT and general industry customers.

Spectral wavelength380nm~980nm

Number of spectral channels31 Channels

Spatial resolution1600*1200

Spectral pixel size1.75µm

Frame rate30fps

SEE8820

SEE8820

Snapshot VIS-NIR Multi-spectral Imaging Camera

The camera enabling acquisition of multi-spectral image information in a single exposure, thereby achieving a high-speed multi-spectral image capture capability of up to 30fps. The device is equipped with the NVIDIA JETSON platform, providing high-speed processing capability for real-time restoration. It is also equipped with a variety of external data interfaces (USB 3.0, HDMI, WLAN, etc.) for convenient communication with PCs and other host devices.

Spectral wavelength380nm~980nm

Number of spectral channelsUp to 31 Channels

Minimum output step size20nm

Color coordinate (CIE1931x,y) deviation0.006~0.02

Brightness accuracy±5%

Spectral resolution50nm

Offline high-speed preview mode frame rate30fps

Offline restoration frame rate1.2fps

PC mode restoration frame rate5~8fps

APPLICATION SCENARIO

CONSUMER ELECTRONICS

CONSUMER ELECTRONICS

AUTOPILOT

AUTOPILOT

MEDICAL APPLICATION

MEDICAL APPLICATION

INDUSTRIAL SORTING

INDUSTRIAL SORTING

DISPLAY SCREEN DETECTION

DISPLAY SCREEN DETECTION

< >
